From analysing to realization

ANALOG/MIXED-SIGNAL SIMULATION

From analyzing to realizing, you can achieve your circuits' performance, behavior, and optimization goals. As the digital age continues to evolve, so too have the challenges Engineers face designing analog, mixed-signal circuits.



  • Ensures design intent, performance, and reliability
  • Improves productivity and data integrity.
  • Helps determine which components affect circuit performance or values needed to improve signal quality.
  • Speed-up review and analysis through data measurements, waveform viewers, and post processing calculators.
  • Lowers system cost

Advanced Analyses

Evaluate circuit operations beyond nominal conditions <br>

Improve quality and maximize performance, reliability, and robustness

  • Parameter sweep – sweep any parameter
  • Sensitivity – determine performance sensitivity to any design parameter
  • Monte Carlo – quantify performance and yield over range of tolerances
  • Worst Case – evaluate circuit operation at component tolerance maximums

Reduce project risk and account for environmental effects / variations

Analog Mixed-Signal Simulation Matters

As the digital age continues to evolve, so too have the challenges Engineers face designing analog, mixed-signal circuits.

Why you should care about mixed-signals in your electronics design? Request our whitepaper!
