FPGA Design

Is your FPGA design flow ready for the new class of designs targeting the latest complex FPGAs? Are you struggling with point tools that don’t work together? Are you able to meet your QoR goals in the desired budget? Can your PCB and FPGA teams collaborate to achieve the overall system constraints?

Siemens EDA’s FPGA design flow is the solution.

schedule a demo with an FPGA expert

Complete FPGA Design Flow
Speed up FPGA designs from creation to board
Delivers integrated FPGA design entry, synthesis, verification, equivalence checking

Siemens EDA's Complete FPGA Design Flow

Siemens EDA’s FPGA design solutions deliver an integrated FPGA design entry, synthesis, verification, equivalence checking, and PCB design platform that speeds up FPGA designs from creation to board, meeting design QoR goals and system constraint requirements.

New Class of FPGA Designs & Methodologies

FPGAs are increasingly being used in fast-evolving market segments (such as 5G, ML and AI) and safety-critical/high-reliability designs. This class of designs requires use of newer methodologies such as HLS or SEE mitigation. Additionally, it poses challenges to debug and verify these large designs.

Safe & Reliable FPGA Design

For safety-critical designs, Precision Hi-Rel provides fail-safe mechanisms (detect, mask, mitigate) to reduce the probability of soft error occurrence and propagation due to radiation, vibration or other environmental conditions.

Mitigate Your Design

Accelarate C++/SystemC Design on FPGAs

Tight integration and better arithmetic operator estimation between Catapult and Precision FPGA Synthesis tool are critical in achieving optimal QoR and faster time to design closure for C++/SystemC designs.

Catapult your FPGA Design

Is Gate-Level Simulation too Slow?

Integration between FormalPro and Precision FPGA Synthesis tool ensures orders of magnitude faster verification of synthesized gate-level netlist against golden RTL designs with complex DSP and RAMs.

Verify Using LEC

FPGA Design Solutions

Siemens EDA's FPGA design solutions deliver the most complete, integrated, and best-performing FPGA design to board flow in the EDA industry.

FPGA/PCB Co-Design

Eliminate the barriers between FPGA and PCB design organizations, enabling concurrent design processes with greater accuracy and speed. Optimize the FPGA I/O in the context of…

HDL Designer

HDL Designer combines deep analysis capabilities, advanced creation editors and complete project flow management, that increases the productivity and enables a repeatable, predictable…

Cost-effective HDL Simulation

ModelSim's award-winning Single Kernel Simulator (SKS) technology enables transparent mixing of VHDL and Verilog in one design.

FormalPro

Uses static formal verification techniques to prove design is functionally identical to its golden reference. Designs that take days or weeks can be verified in hours or even minutes…

Catapult HLS & Verification

Industry-leading C++/SystemC High-Level Synthesis with Low-Power estimation/optimization. Design checking, code, and functional coverage verification plus formal make HLS more…

Precision FPGA Synthesis

Precision Synthesis offers high-quality results, industry-unique features, and integration across Siemens EDA's FPGA flow - the industry's most comprehensive FPGA vendor-independent…
